Fueling Growth Through Pipe.
High-density and medium-density polyethylene (HDPE and MDPE) piping systems are Canada’s preferred choice for gas distribution due to their exceptional durability, flexibility, and safety features. Alexander Tubular enhances these qualities to new heights with advanced extruding equipment, testing standards, and recycling protocols for uncompromising and cost-effective products to meet your scheduled needs.
Alexander Tubular is proud to manufacture First Nation owned, Canadian made HDPE and MDPE pipe to the following conformance standards for gas distribution:
HDPE and MDPE piping is well-suited for a wide range of gas distribution scenarios, from custom residential and commercial service lines to large-scale municipal and industrial networks. Alexander Tubular’s adaptability and history of municipal success support both new installations and the rehabilitation of aging infrastructure, offering a future-ready solution for expanding and modernizing gas delivery systems nationwide.
Alexander Tubular is proud to support local communities. Sourcing First-Nation and Canadian-made manufactured HDPE and MDPE gas pipe means lower transportation costs, reduced risk of delay, and greater community stewardship during complex gas delivery projects.
| Pipe Size | Pipe True Size (OD") | SDR | Weight (LBs) | Packaging | Length | Reels on a Truck (53") | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| IPS | in | mm | /Ft | /M | Reel Material | Reel Dia | Meters | Feet | |||
| 3/4" | 1.051 | 26.7 | 1.050 | 11 | 0.126 | 0.412 | Wood | 60" | 1900 | 6234 | 20 |
| 1" | 1.315 | 33.4 | 1.315 | 11 | 0.197 | 0.645 | Wood | 70" | 1200 | 3937 | 18 |
| 1-1/4" | 1.661 | 42.2 | 1.660 | 10 | 0.341 | 1.120 | Wood | 84" | 1000 | 3281 | 14 |
| 1-1/2" | 1.902 | 48.3 | 1.900 | 11 | 0.411 | 1.348 | Wood | 84" | 800 | 2625 | 14 |
| 2" | 2.374 | 60.3 | 2.375 | 11 | 0.642 | 2.107 | Wood | 84" | 600 | 1969 | 14 |
| 3" | 3.500 | 88.9 | 3.500 | 11 | 1.395 | 4.576 | Wood | 112" | 500 | 1640 | 10 |
| 4" | 4.500 | 114.3 | 4.500 | 11 | 2.306 | 7.564 | Wood | 130" | 400 | 1312 | 8 |
Your safety commitments begin with quality materials. HDPE and MDPE pipes are permanently joined using heat fusion, resulting in seamless connections that virtually eliminate leak points for superior integrity in gas delivery systems.
Unlike traditional metal pipes, such as black steel, HDPE and MDPE pipe is resistant to corrosion and a wide range of chemicals in your gas distribution system. This chemical resilience ensures a longer service life and reduces the need for additional coatings or cathodic protection systems.
Quality HDPE and MDPE pipe flexibility allows it to withstand ground movements, complex installations, and thermal expansions without cracking. The lightweight nature of HDPE and MDPE pipe also simplifies transportation and installation, resulting in cost savings and faster project completion with a lower risk of rework.
HDPE and MDPE pipe is preferred in gas distribution because it is lightweight, flexible, resistant to corrosion, and has excellent long-term performance in underground installations. Its fusion-welded joints create a leak-free system, reducing the risk of gas leakage compared to traditional metal piping.
In North America, HDPE and MDPE gas distribution pipes typically comply with ASTM D2513 (US) and CSA B137.4 (CAN) and must meet the DOT (Department of Transportation) regulations for gas piping systems. Pipes are classified by PE material grade (e.g., PE2708, PE4710) and all materials are tested for pressure, slow-crack growth resistance, and long-term strength.
The primary joining methods are butt fusion, electrofusion, and mechanical fittings. Butt fusion and electrofusion create a homogenous joint that is as strong as or stronger than the pipe itself. These fusion methods ensure a leak-free system, which is critical for gas safety.
The pressure rating depends on the pipe’s material grade, SDR (Standard Dimension Ratio), and operating temperature. For example, PE4710 HDPE pipe with an SDR 11 typically has a pressure rating of around 200 psi at 73°F (23°C). Engineers must select the correct SDR and PE grade based on system design and regulatory requirements.
Industrial, commercial,
& municipal expertise
Materials for the real world
Alexander Tubular manufactures PE100 and PE4710 HDPE and MDPE pipe to meet top industry standards. With CSA and NSF approved products and operations aligning with ISO 9001:2015, we deliver consistent quality, safety, and reliability.
